Overview

The Kubota KC70-4 Track Dumper is a compact, powerful, and versatile material transport solution designed for construction, landscaping, agriculture, and property maintenance applications. Built to handle demanding jobs in tight spaces, the KC70-4 combines Kubota reliability with excellent maneuverability, allowing operators to move materials efficiently where larger machines cannot access.

Powered by a dependable Kubota diesel engine, the KC70-4 delivers strong torque, fuel-efficient performance, and reliable operation in challenging work environments. With a maximum payload capacity of 1,543 lb (700 kg), this compact crawler carrier is ideal for transporting soil, gravel, mulch, stone, debris, and other materials around job sites.

The rubber track undercarriage provides excellent traction while reducing ground disturbance compared to traditional wheeled machines. Its compact 34.6-inch width allows easy access through gates, narrow pathways, and confined work areas, making it an excellent choice for landscaping contractors, rental fleets, municipalities, and construction professionals.

Featuring hydraulic front dumping, a durable steel skip, and a smooth travel system, the Kubota KC70-4 helps operators save time and reduce physical effort when moving materials. Its simple design, rugged construction, and low-maintenance components make it a dependable machine for daily productivity.

Key Features

• Compact rubber track carrier design for tight-access applications
• Maximum payload capacity of 1,543 lb (700 kg)
• Kubota diesel engine providing reliable power and fuel efficiency
• Narrow 34.6" overall width for excellent job-site accessibility
• Hydraulic front dump system for fast unloading
• 68° dumping angle for efficient material discharge
• Rubber crawler tracks provide improved traction and reduced ground pressure
• Excellent stability on uneven terrain
• Mechanical transmission with multiple forward and reverse speeds
• Ideal for landscaping, construction, agriculture, and rental applications
• Low-maintenance design built for long service life

Factory Specifications

Manufacturer: Kubota
Model: KC70-4
Equipment Type: Rubber Track Dumper / Track Carrier

Engine

• Engine Model: Kubota OC60
• Engine Type: Diesel
• Gross Horsepower: 5.6 HP (4.1 kW)
• Displacement: 276 cc
• Cylinders: 1
• Fuel Tank Capacity: 3.5 L (0.92 gal)

Capacity

• Maximum Payload Capacity: 1,543 lb (700 kg)
• Bed Length: 49.2 in (1,250 mm)
• Bed Width: 32.3 in (820 mm)
• Bed Height: 13.8 in (360 mm)
• Struck Capacity: 0.30 m³ (0.39 yd³)
• Heaped Capacity: 0.36 m³ (0.47 yd³)

Dimensions & Weight

• Operating Weight: 922 lb (450 kg)
• Overall Length: 95.1 in (2,415 mm)
• Overall Width: 34.6 in (880 mm)
• Overall Height: 51.6 in (1,310 mm)
• Ground Clearance: 5.1 in (130 mm)

Undercarriage

• Track Width: 7.9 in (200 mm)
• Track Contact Length: 38.9 in (980 mm)
• Track Centre Distance: 24.4 in (620 mm)

Performance

• Travel Speed Forward: 3.1 mph (5 km/h)
• Travel Speed Reverse: 2.9 mph (4.8 km/h)
• Transmission: Mechanical
• Forward Speeds: 3
• Reverse Speeds: 3
• Dumping System: Hydraulic
• Dump Direction: Front
• Dump Angle: Approximately 68°

Specifications may vary depending on model configuration, attachments, and optional equipment.

Why Choose the Kubota KC70-4?

The Kubota KC70-4 Track Dumper is designed for operators who need dependable material handling performance in areas where traditional dump trucks and loaders cannot operate. Its compact footprint, strong payload capacity, and rubber track system make it a valuable machine for increasing productivity while minimizing site disturbance.

Whether moving landscaping materials, preparing construction sites, maintaining properties, or transporting materials through confined areas, the KC70-4 delivers the durability and performance expected from Kubota equipment.
