Overview

The Kubota KX033-4 Mini Excavator delivers the perfect combination of power, versatility, and compact performance for contractors, landscapers, farmers, and property owners. Designed as a 3.3-ton class excavator, the KX033-4 provides exceptional digging capability while maintaining the maneuverability needed for tight job sites and confined work areas.

Powered by a reliable Kubota diesel engine producing 24.8 gross horsepower, the KX033-4 delivers smooth, efficient performance with the durability expected from Kubota construction equipment. Its advanced hydraulic system provides excellent digging force, attachment capability, and precise control for a wide range of applications including trenching, landscaping, utility work, drainage, demolition, and general excavation.

With a maximum digging depth of approximately 10 ft. 6 in., the KX033-4 offers impressive reach and productivity in a compact package. The machine’s reduced tail swing design, comfortable operator station, and excellent visibility help operators work efficiently while maintaining control in demanding environments.

The KX033-4 is built with operator comfort and productivity in mind. Features such as two-speed travel with auto downshift, programmable auxiliary hydraulic flow, a spacious operator platform, and durable undercarriage components make this excavator an excellent choice for daily professional use.

Whether you are digging foundations, installing utilities, preparing landscapes, or maintaining rural properties, the Kubota KX033-4 provides the reliability, versatility, and performance needed to complete jobs efficiently.

Key Features

• 24.8 HP Kubota diesel engine for reliable power and fuel efficiency
• 3.3-ton class compact excavator design
• Maximum digging depth of 10 ft. 6 in.
• Powerful hydraulic system for excellent digging performance
• Bucket breakout force of 8,138 lb
• Arm breakout force of 3,867 lb
• Two-speed travel system with automatic downshift
• Rubber or steel track options available
• Compact 61 in. width for improved job-site access
• Spacious operator platform with excellent visibility
• Programmable auxiliary hydraulic flow for attachments
• Compatible with breakers, augers, compactors, thumbs, and other excavator attachments
• Durable Kubota construction designed for long service life

Factory Specifications

Manufacturer: Kubota
Model: KX033-4
Equipment Type: Compact Mini Excavator

Engine

Engine Model: Kubota D1703M-DI-E4
Engine Type: 3-cylinder diesel
Gross Horsepower: 24.8 HP (18.5 kW)
Net Horsepower: 23.2 HP (17.3 kW)
Displacement: 100.5 cu. in. (1,647 cc)
Rated Engine Speed: 2,200 RPM

Hydraulic System

Pump Capacity: 10.5 GPM (39.6 L/min)
Auxiliary Hydraulic Flow: Up to 15.8 GPM (60 L/min)
Bucket Breakout Force: 8,138 lb (3,694 kgf)
Arm Breakout Force: 3,867 lb (1,756 kgf)

Working Range

Maximum Digging Depth: 10 ft. 6 in. (3,210 mm)
Maximum Digging Height: 16 ft. 4 in. (4,980 mm)
Maximum Dumping Height: 11 ft. 7 in. (3,530 mm)
Maximum Digging Radius: 17 ft. 2 in. (5,230 mm)

Dimensions & Weight

Operating Weight: 7,245 lb (3,286 kg)
Operating Weight Including Operator: Approximately 8,300 lb (3,764 kg)
Overall Width: 61 in. (1,550 mm)
Overall Height: 97 in. (2,480 mm)
Overall Length: 186 in. (4,730 mm)
Ground Clearance: 11.4 in. (290 mm)

Undercarriage

Track Type: Rubber or Steel
Track Width: 11.8 in. (300 mm)
Crawler Length: 82.6 in. (2,100 mm)
Travel Speed Low: 1.9 mph
Travel Speed High: 2.9 mph
Maximum Traction Force: 6,091 lb

Capacities

Fuel Tank Capacity: 12.4 gal (46.9 L)
Hydraulic Oil Reservoir: 11.8 gal (44.6 L)
Hydraulic System Capacity: 16.1 gal (61 L)

Specifications may vary depending on machine configuration, cab/canopy options, attachments, and optional equipment.

Why Choose the Kubota KX033-4?

The Kubota KX033-4 is engineered for operators who need professional excavation performance in a compact and versatile machine. Its combination of strong hydraulic power, reliable Kubota diesel performance, and easy maneuverability makes it an ideal excavator for contractors and property owners who demand dependable results.

From digging trenches and foundations to landscaping, utility installation, and site preparation, the KX033-4 provides the performance and flexibility needed to tackle a wide variety of projects.

Kubota original direct injection engine

The KX033-4 is powered by Kubota’s impressive direct injection engine. Engineered with the power to maximize digging and lifting performance, it also delivers minimized noise, vibration and fuel consumption, and is as well a non-DOC/DPF Tier 4 Final certified engine.

Angle blade optional hydraulic blade*

Save time and work more efficiently. With a simple movement of the new thumb operated rocker switch on the dozer lever, the hydraulic angle blade (optional) can be angled to the right or left to push soil to the side as the machine moves forward, eliminating the need for repetitive repositioning at right angles when backfilling trenches.

Comfort & convenience

A spacious operator station designed for greater comfort, with a fully flat floor for more legroom, digital panel with easy access, simple settings and easy-to-read indicators and alerts. An option, the cab allows for easy entry and exit, with an easy-open front slide window.

2-speed travel with auto down shift

By placing the 2-speed travel switch on the dozer lever, dozing operations can be done faster and easier. The KX033-4 auto-shift automatically shifts travel speed from high to low, depending on traction and terrain, allowing smoother operation when dozing and turning.

Proportional flow control of auxiliary circuit

Now you can conveniently program up to five different oil flow rates for specific attachments on the new digital control panel. No tools or manual adjustment is required. And, with a maximum AUX 1 circuit oil flow now up to 15.8 GPM (60 liters) you can operate a larger variety of auxiliary attachments than ever before.
